300V 105C Halogen-free Non-shielded TPE Cable UL2838, UL20618, UL21002, UL21556

Brand Name : WCH Cable

Model Number : UL2838

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 1220 meters

Price : USD0.10 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 305 meters per spool / reel

Conductor : Pure Copper Conductor

Insulation : AWM Material

Rated Voltage : 300V

Rated Temperature : 105C

Jacket Material : Thermoplastic Elastomer TPE

Style Number1 : UL2838, UL20618

Feature : Halogen Free

Style Number2 : UL21002, UL21556

Contact Now

Approval style number: UL2838

Rated temperature and voltage: 105 deg C, 300 Vac.

Conductor: pure copper wire conductor.

Insulation material and wall thickness: Extruded TPE, 30 mils min average, 20 mils minimum at any point.

Jacket material and wall thickness: Extruded TPE, 25 mils min average, 20 mils minimum at any point.

Applied standard: Appliance Wiring Material UL 758.

Application: Pipe Heating Cable where the acceptability of the combination is to be determined.

Origin: Dongguan, China

Equivalent approval style numbers of 300V 105C Halogen-free Non-shielded TPE Cable:

Approval Style Temperature Voltage Material Brand
UL 2838 105 300 Thermoplastic Elastomer / TPE WCH Cable
UL 20618 105 300 Thermoplastic Elastomer / TPE WCH Cable
UL 21002 105 300 Thermoplastic Elastomer / TPE WCH Cable
UL 21556 105 300 Thermoplastic Elastomer / TPE WCH Cable

Parameters of 300V 105C Halogen-free Non-shielded TPE Cable:

Approval Style Number Cores Conductor Insulation
Thickness		 Nom.Dia Shield Coverage Jacket Thickness Overall
Diameter		 Conductor
Resistance
AWG No/mm mm mm % mm mm Ω/KM
UL2838 2C 18 34/0.178 0.76 2.80 >=65 0.64 7.80 23.20
16 26/0.25 0.76 3.10 >=65 0.64 8.40 14.60
14 41/0.25 0.76 3.50 >=65 0.64 9.20 8.96
UL2838 3C 18 34/0.178 0.76 2.80 >=65 0.64 8.20 23.20
16 26/0.25 0.76 3.10 >=65 0.64 9.00 14.60
14 41/0.25 0.76 3.50 >=65 0.64 10.00 8.96
